Materials of Construction
Funnel Housing: Type 316 stainless steel
Support Screen, Retaining Ring Assembly, and Base: Type 304 stainless steel
Effective Filtration Area
9.6 cm2
Dimensions
Overall Length: 22.2 cm (8.7 in.)
Diameter: 15.2 cm (6.0 in.)
Filter Size
Accepts 47 mm filter
Funnel Capacity
1 L
Connection
Stem inserts into standard size No. 2 rubber stopper
Maximum Operating Temperature
Limited by filter type
Sterilization
Provided non-sterile. Autoclavable if desired at 121 - 123°C (250 - 253°F) at 1.0 bar (100 kPa, 15 psi) for 15 - 20 min.
Note: Not recommended for use with volatile liquids or high purity fuels as explosion may result from the static discharge.
Applications
For large-volume vacuum filtration of microbiological samples, oils, and solvents.
This product is designed for laboratory applications only and is not approved for use in medical, clinical, surgical or other patient applications.
