Membrany typu AE z azotanu celulozy
Filtry membranowe Whatman™ AE z azotanu celulozy charakteryzujące się doskonałą elastycznością i niskim poziomem substancji ekstrahowalnych, co zapewnia integralność próbki. Wąski rozkład wielkości porów tych filtrów zapewnia lepsze wychwytywanie i analizę powierzchni.
A range of unbacked nitrocellulose membranes for use in a lateral flow assay.

• AE membranes are unbacked, allowing either belt or air side of the membrane to be used.
• Enables assay suitability tests of both air and belt side of the membrane.
• Constructed of 100% nitrocellulose.

AE Membranes

Constructed of 100% nitrocellulose, the AE family of membranes offers a higher level of purity and performance compared to post-treated materials. The AE membranes have been used extensively since the development of the original lateral-flow tests and have become a standard for manufacturers worldwide. There is a long history of success and experience for the optimization of these products in assays. AE membranes are unsupported, which means either the belt or air side of the membrane can be used.

Nitrocellulose Membranes

Nitrocellulose membranes are a key functional part of lateral-flow assays. The membrane must provide sufficient protein binding to enable the formation of a sharp and intense capture line, but at the same time the level of nonspecific background must be low for easy interpretation of results. Nitrocellulose membranes are available in a range of wicking rates and formulations. It has long been known that the wicking rate of a membrane has a significant impact on test sensitivity.
Membrany typu AE z azotanu celulozy
Membrany typu AE z azotanu celulozy
Autoclavable Yes
Color White
Hydrophobic No
Hydrophilic Yes
Material Cellulose Nitrate
Membrane Type Plain
Operating temp. max. 80°C
Pore Size 5, 8, 12 µm
Sterility Nonsterile
Nr kat. Opis produktu Pory Rozmiar
10400206 AE98 Membrane Circles, Cellulose nitrate, 5,0 um, 25 mm 100/pk 5,0 um 25 mm
10400212 AE98 Membrane Circles, Cellulose nitrate, 5,0 um, 47 mm 100/pk 5,0 um 47 mm
10400214 AE98 Membrane Circles, Cellulose nitrate, 5,0 um, 50 mm 100/pk 5,0 um 50 mm
10549916 AE98 Membrane Roll, Cellulose nitrate, 5,0 um, roll 25 mm x 50m 1/pk 5,0 um 25 mm x 50m
10400106 AE99 Membrane Circles, Cellulose nitrate, 8,0 um, 25 mm 100/pk 8,0 um 25 mm
10400112 AE99 Membrane Circles, Cellulose nitrate, 8,0 um, 47 mm 100/pk 8,0 um 47 mm
10400114 AE99 Membrane Circles, Cellulose nitrate, 8,0 um, 50 mm 100/pk 8,0 um 50 mm
10405076 AE99/5 Membrane Circles, Cellulose nitrate, 8,0 um with hydrophobic rim, 47 mm 100/pk 8,0 um 47 mm
10405079 AE99/5 Membrane Circles, Cellulose nitrate, 8,0 um with hydrophobic rim, 50 mm 100/pk 8,0 um 50 mm
10400012 AE100 Membrane Circles, Cellulose nitrate, 12,0 um, 47 mm 100/pk 8,0 um 47 mm
10400014 AE100 Membrane Circles, Cellulose nitrate, 12,0 um, 50 mm 100/pk 8,0 um 50 mm
