VACU-GUARD 150

Filtry zabezpieczające dostępne z różnymi typami pułapek chemicznych: z węglem aktywnym, sitem molekularnym lub środkiem osuszającym.
VACU-GUARD 150 capsule filters available with a choice of chemical traps: activated carbon, molecular sieve, or desiccant.

• Excellent for protecting vacuum pump systems from solvent vapor or gaseous contaminants and aqueous aerosols.
• Designed for in-line use with stepped barb connections for 10 to 12 mm i.d. hose.
• Available with choice of chemical trap: activated carbon, molecular sieve, or desiccant.
• Membrane retains 99.99% of airbone particles greater than 0.1 µm.
• Features hydrophobic polytetrafluoroethylene (PTFE) membrane.

The easy-to-use VACU-GUARD inline filter devices help to confine and isolate infectious materials in vacuum systems and protect your laboratory.
VACU-GUARD 150
VACU-GUARD 150
Inlet Connector Hose barb / stepped barb
Outlet Connector Hose barb / stepped barb
Housing Polypropylene (PP)
Operating pressure max. 1 bar (15 psi)
Filter Media Polytetrafluoroethylene (PTFE)
Retentions Aqueous solutions: up to 0.9 bar (14 psi) Particulates in air: 0.1 µm 99.99%
Product Product Name Chemical Trap Media
6722-1001 VACU-GUARD 150; activated carbon Activated carbon
6722-1002 VACU-GUARD 150; desiccant Anhydrous calcium sulfate
6722-1003 VACU-GUARD 150; molecular sieve Silico aluminate zeolite
