Filtry strzykawkowe Acrodisc z membraną uniwersalną  (wwPTFE)
Uniwersalne filtry strzykawkowe do filtracji analitycznych.
Acrodisc™ syringe filters with universal membrane, a Pall Life Sciences product, are chemically compatible with a wide variety of common solvents and are suitable for use in both aqueous and organic applications.

Avoid the expense and inconvenience of keeping a variety of filters on hand. Versatile filter for aqueous and aggressive organic solvent-based solutions.
Low protein binding membrane gives high recovery of critical proteinaceous samples.
Accurate analysis. HPLC certified for low levels of UV-absorbing extractables.
Easy filtration of particulate-laden samples with glass fiber prefilter version.
13 mm Acrodisc syringe filter with minispike configuration offers low hold-up and easy filtration into autosampler vials.
Protects columns and instrumentation from particulate buildup better than other filters
Filtry strzykawkowe Acrodisc z membraną uniwersalną
Materials of Construction
Filter Media: Water wettable polytetrafluoroethylene (wwPTFE)
Housing: Polypropylene
GxF Prefilter: Binder-free borosilicate glass

Pore Size
0.2 and 0.45 μm
Glass Fiber: 1 μm
GxF Prefilter: 40 - 1 μm

Effective Filtration Area
4 mm: 0.2 cm2
13 mm: 1.0 cm2
25 mm: 2.8 cm2
25 mm PSF: 3.9 cm2

Sample Volume
13 mm: < 10 mL
25 mm PSF: < 150 mL

Inlet/Outlet Connections
13 mm: Female luer lok inlet, minispike outlet
25 mm PSF: Female luer lok inlet, male slip luer outlet

Typical Hold-up Volume(with air purge)
13 mm: < 14 µL
25 mm PSF: < 125 µL
25 mm PSF GxF: < 200 µL

Maximum Operating Temperature
25 mm PSF: 55°C (131°F) at 2.1 bar (210 kPa, 30 psi)

Maximum Operating Pressure
13 mm: 6.3 bar (630 kPa, 90 psi)
25 mm PSF: 4.1 bar (410 kPa, 60 psi) at 21 - 24°C (70 - 75°F); 2.1 bar (210 kPa, 30 psi) at 55°C (131°F)

Typical Water Flow Rate
mL/min at 0.7 bar (70 kPa, 10 psi)
13 mm, 0.2 µm: 17
13 mm, 0.45 µm: 28
mL/min at 2.1 bar (210 kPa, 30 psi)
Acrodisc One: 0.2 µm: 151 0.45 µm: 263
25 mm PSF, 0.2 µm: 215 0.45 µm: 300
25 mm GxF/PSF, 0.2 µm: 175 0.45 µm: 195

Applications
Highly recommended for filtering HPLC samples
Available in 0.2 μm for UHPLC applications
The Acrodisc PSF GxF syringe filter provides two to four times the throughput of standard prefilter devices for particulate-laden samples
25 mm Acrodisc PSF syringe filter is available in robotic-compatible AutoPack™ packaging.
Nr kat. Opis produktu Membrana Pory Średnica Opak.
AP-4912 PSF Acrodisc One wwPTFE syringe filter, 0,2 um, 25 mm (1000/pkg) wwPTFE 0,2 um 25 mm 1000/pkg
AP-4911 PSF Acrodisc One wwPTFE syringe filter, AutoPack tubes, 0,2 um, 25 mm (25/pkg, 200/cs) wwPTFE 0,2 um 25 mm 25/pkg 200/cs
AP-4913TC PSF Acrodisc One GXF/wwPTFE syringe filter, 0,2 um, 25 mm (50/pkg) GxF / wwPTFE 0,2 um 25 mm 50/pkg
AP-4916 PSF Acrodisc One wwPTFE syringe filter, 0,45 um, 25 mm (50/pkg, 200/cs) wwPTFE 0,45 um 25 mm 50/pkg 200/cs
AP-4919TC PSF Acrodisc One GXF/wwPTFE syringe filter, 0,45 um, 25 mm (50/pkg) GxF / wwPTFE 0,45 um 25 mm 50/pkg
AP-4910 PSF Acrodisc One wwPTFE syringe filter, 0,2 um, 25 mm (50/pkg, 200/cs) wwPTFE 0,2 um 25 mm 50/pkg 200/cs
AP-4917 PSF Acrodisc One wwPTFE syringe filter, AutoPack tubes, 0,45 um, 25 mm (25/pkg, 200/cs) wwPTFE 0,45 um 25 mm 25/pkg 200/cs
AP-4918 PSF Acrodisc One wwPTFE syringe filter, 0,45 um, 25 mm (1000/pkg) wwPTFE 0,45 um 25 mm 1000/pkg
AP-4910TC PSF Acrodisc One wwPTFE syringe filter, 0,2 um, 25 mm (50/pkg) wwPTFE 0,2 um 25 mm 50/pkg
AP-4913 PSF Acrodisc One GXF/wwPTFE syringe filter, 0,2 um, 25 mm (50/pkg, 200/cs) GxF / wwPTFE 0,2 um 25 mm 50/pkg 200/cs
2400TC Acrodisc wwPTFE syringe filter, 0,2 um, 13 mm, minispike outlet (100/pkg) wwPTFE 0,2 um 13 mm 100/pkg
AP-4915 PSF Acrodisc One GXF/wwPTFE syringe filter, 0,2 um, 25 mm (1000/pkg) GxF / wwPTFE 0,2 um 25 mm 1000/pkg
4914TC Acrodisc wwPTFE syringe filter, 0,45 um, 25 mm (50/pkg) wwPTFE 0,45 um 25 mm 50/pkg
4927TC Acrodisc wwPTFE syringe filter, 0,2 um, 25 mm (50/pkg) wwPTFE 0,2 um 25 mm 50/pkg
2402TC Acrodisc wwPTFE syringe filter, 0,45 um, 13 mm, minispike outlet (100/pkg) wwPTFE 0,45 um 13 mm 100/pkg
4927 Acrodisc wwPTFE syringe filter, 0,2 um, 25 mm (50/pkg, 200cs) wwPTFE 0,2 um 25 mm 50/pkg 200/cs
2403 Acrodisc wwPTFE syringe filter, 0,45 um, 13 mm, minispike outlet (1000/pkg) wwPTFE 0,45 um 13 mm 1000/pkg
4914 Acrodisc wwPTFE syringe filter, 0,45 um, 25 mm (50/pkg, 200/cs) wwPTFE 0,45 um 25 mm 50/pkg 200/cs
2402 Acrodisc wwPTFE syringe filter, 0,45 um, 13 mm, minispike outlet (100/pkg, 300/cs) wwPTFE 0,45 um 13 mm 100/pkg 300/cs
4929 Acrodisc wwPTFE syringe filter, 0,2 um, 25 mm (1000/pkg) wwPTFE 0,2 um 25 mm 1000/pkg
2401 Acrodisc wwPTFE syringe filter, 0,2 um, 13 mm, minispike outlet (1000/pkg) wwPTFE 0,2 um 13 mm 1000/pkg
2400 Acrodisc wwPTFE syringe filter, 0,2 um, 13 mm, minispike outlet (100/pkg, 300/cs) wwPTFE 0,2 um 13 mm 100/pkg 300/cs
AP-4919 PSF Acrodisc One GXF/wwPTFE syringe filter, 0,45 um, 25 mm (50/pkg, 200/cs) GxF / wwPTFE 0,45 um 25 mm 50/pkg 200/cs
AP-4920 PSF Acrodisc One GXF/wwPTFE syringe filter, AutoPack tubes 0,45 um, 25 mm (25/pkg, 200/cs) GxF / wwPTFE 0,45 um 25 mm 25/pkg 200/cs
AP-4921 PSF Acrodisc One GXF/wwPTFE syringe filter, 0,45 um, 25 mm (1000/pkg) GxF / wwPTFE 0,45 um 25 mm 1000/pkg
4932 Acrodisc wwPTFE syringe filter, 0,45 um, 25 mm (1000/pkg) wwPTFE 0,45 um 25 mm 1000/pkg
AP-4916TC PSF Acrodisc One wwPTFE syringe filter, 0,45 um, 25 mm (50/pkg) wwPTFE 0,45 um 25 mm 50/pkg
AP-4914 PSF Acrodisc One GXF/wwPTFE syringe filter, AutoPack tubes, 0,2 um, 25 mm (25/pkg, 200/cs) GxF / wwPTFE 0,2 um 25 mm 25/pkg 200/cs
AP-4912;PSF Acrodisc One wwPTFE syringe filter, 0.2 µm, 25 mm (1000/pkg);wwPTFE;0.2 μm;25 mm;1000/pkg
AP-4911;PSF Acrodisc One wwPTFE syringe filter, AutoPack tubes, 0.2 µm, 25 mm (25/pkg, 200/cs);wwPTFE;0.2 μm;25 mm;25/pkg 200/cs
AP-4913TC;PSF Acrodisc One GXF/wwPTFE syringe filter, 0.2 µm, 25 mm (50/pkg);GxF / wwPTFE;0.2 μm;25 mm;50/pkg
AP-4916;PSF Acrodisc One wwPTFE syringe filter, 0.45 µm, 25 mm (50/pkg, 200/cs);wwPTFE;0.45 µm;25 mm;50/pkg 200/cs
AP-4919TC;PSF Acrodisc One GXF/wwPTFE syringe filter, 0.45 µm, 25 mm (50/pkg);GxF / wwPTFE;0.45 µm;25 mm;50/pkg
AP-4910;PSF Acrodisc One wwPTFE syringe filter, 0.2 µm, 25 mm (50/pkg, 200/cs);wwPTFE;0.2 μm;25 mm;50/pkg 200/cs
AP-4917;PSF Acrodisc One wwPTFE syringe filter, AutoPack tubes, 0.45 µm, 25 mm (25/pkg, 200/cs);wwPTFE;0.45 µm;25 mm;25/pkg 200/cs
AP-4918;PSF Acrodisc One wwPTFE syringe filter, 0.45 µm, 25 mm (1000/pkg);wwPTFE;0.45 µm;25 mm;1000/pkg
AP-4910TC;PSF Acrodisc One wwPTFE syringe filter, 0.2 µm, 25 mm (50/pkg);wwPTFE;0.2 μm;25 mm;50/pkg
AP-4913;PSF Acrodisc One GXF/wwPTFE syringe filter, 0.2 µm, 25 mm (50/pkg, 200/cs);GxF / wwPTFE;0.2 μm;25 mm;50/pkg 200/cs
2400TC;Acrodisc wwPTFE syringe filter, 0.2 µm, 13 mm, minispike outlet (100/pkg);wwPTFE;0.2 μm;13 mm;100/pkg
AP-4915;PSF Acrodisc One GXF/wwPTFE syringe filter, 0.2 µm, 25 mm (1000/pkg);GxF / wwPTFE;0.2 μm;25 mm;1000/pkg
4914TC;Acrodisc wwPTFE syringe filter, 0.45 µm, 25 mm (50/pkg);wwPTFE;0.45 µm;25 mm;50/pkg
4927TC;Acrodisc wwPTFE syringe filter, 0.2 µm, 25 mm (50/pkg);wwPTFE;0.2 μm;25 mm;50/pkg
2402TC;Acrodisc wwPTFE syringe filter, 0.45 µm, 13 mm, minispike outlet (100/pkg);wwPTFE;0.45 µm;13 mm;100/pkg
4927;Acrodisc wwPTFE syringe filter, 0.2 µm, 25 mm (50/pkg, 200cs);wwPTFE;0.2 μm;25 mm;50/pkg 200/cs
2403;Acrodisc wwPTFE syringe filter, 0.45 µm, 13 mm, minispike outlet (1000/pkg);wwPTFE;0.45 µm;13 mm;1000/pkg
4914;Acrodisc wwPTFE syringe filter, 0.45 µm, 25 mm (50/pkg, 200/cs);wwPTFE;0.45 µm;25 mm;50/pkg 200/cs
2402;Acrodisc wwPTFE syringe filter, 0.45 µm, 13 mm, minispike outlet (100/pkg, 300/cs);wwPTFE;0.45 µm;13 mm;100/pkg 300/cs
4929;Acrodisc wwPTFE syringe filter, 0.2 µm, 25 mm (1000/pkg);wwPTFE;0.2 μm;25 mm;1000/pkg
2401;Acrodisc wwPTFE syringe filter, 0.2 µm, 13 mm, minispike outlet (1000/pkg);wwPTFE;0.2 μm;13 mm;1000/pkg
2400;Acrodisc wwPTFE syringe filter, 0.2 µm, 13 mm, minispike outlet (100/pkg, 300/cs);wwPTFE;0.2 μm;13 mm;100/pkg 300/cs
AP-4919;PSF Acrodisc One GXF/wwPTFE syringe filter, 0.45 µm, 25 mm (50/pkg, 200/cs);GxF / wwPTFE;0.45 µm;25 mm;50/pkg 200/cs
AP-4920;PSF Acrodisc One GXF/wwPTFE syringe filter, AutoPack tubes 0.45 µm, 25 mm (25/pkg, 200/cs);GxF / wwPTFE;0.45 µm;25 mm;25/pkg 200/cs
AP-4921;PSF Acrodisc One GXF/wwPTFE syringe filter, 0.45 µm, 25 mm (1000/pkg);GxF / wwPTFE;0.45 µm;25 mm;1000/pkg
4932;Acrodisc wwPTFE syringe filter, 0.45 µm, 25 mm (1000/pkg);wwPTFE;0.45 µm;25 mm;1000/pkg
AP-4916TC;PSF Acrodisc One wwPTFE syringe filter, 0.45 µm, 25 mm (50/pkg);wwPTFE;0.45 µm;25 mm;50/pkg
AP-4914;PSF Acrodisc One GXF/wwPTFE syringe filter, AutoPack tubes, 0.2 µm, 25 mm (25/pkg, 200/cs);GxF / wwPTFE;0.2 μm;25 mm;25/pkg 200/cs
